Raw material aluminium
Field of application for nail guns, tack welders, power screwdrivers etc. for direct mount for mobile equipment.
Working pressure Up from 2 bar working pressure the oil-fog lubricator is operational; the max. working pressure is 16 bar. The built-in air screen regulates the discharge cross-section automatically according to the metered flow. Thereby a sufficient oil fumigation in the case of low and high air consumption (from 2 up to ca. 80 Nm³) is warranted.
Oil metering Fix adjusted at about 0,05 - 1 cm³ oil per Nm³ air. Lower or higher oilrates can be adjusted if required.
